Type

Parameters

Unit

Parameters

Wavelength range

nm

1460~1620

1260~1620

Channel centers (ITU or ITU+1)

nm

1470/1490…1610 or 1471/1491…1611

1270/1290…1610 or 1271/1291…1611

Channel

ch

4

8

4

8

Insertion Loss

dB

2.0

2.8

2.0

3.0

Optional insertion loss

dB

1.8

2.6

1.8

2.8

Channel space

nm

20

Channel passband

nm

≥+/-7

Passband ripple

dB

≤0.5

Isolation

Demux Adjacent channel

dB

≥30

Demux Non-adjacent channel

≥45

Mux or Reflection channel

≥15

Directivity

dB

≥50

Return loss

dB

≥45

PDL

dB

≤0.15

PMD

ps

≤0.1

Wavelength thermal stability

nm℃

≤0.003

Insertion loss thermal stability

dB/℃

≤0.005

Operating Temperature

℃

-5~ +70

Storage temperature

-40+~85

Dimension

mm

100×80×10

100×80×10

141×115×18

Customer Design

Note: The above specification is without connector.

Type

Port number

Transmission Wavelength

Pigtail Type

Length

Connector

PackageSize

M:Mux

D:

Demux

1×2

1×3

1×4

Etc

1471,1491,1511,

T1471~1511

Etc.

0:250um

1:900um

2:2mm 3:3mm

4:others

0.5:0.5m

1:1m

3:Others

FP:FC/PC,FC:FC/APC

SP:SC/PC,SA:SC/APC

LP:LC/PC,LA:LC/APC

OO :None X：Others

1:100×80×10mm

2:141×115×18mm
